Xantech ML85 LCD/CFL Proof Micro Link IR Receiver


Xantech ML85 LCD/CFL Proof Micro Link IR Receiver

Item Condition: New


In Stock
List Price $112.99
Your Price $94.99
You Save $18.00 - 16%
Qty

XAN1220

Description

Model ML85 LCD/CFL Proof Micro Link IR Receiver is a small peep-hole style infrared repeater assembly. The Micro Link IR Receiver is equipped with a 7-foot cable and a 3.5mm stereo mini plug, which is plugged directly into the “IR RCVR” jack on the connecting block, such as the models 789-44, CB60, and 791- 44. The Micro Link IR Receiver is primarily intended for use in installations where the connecting block is within reach of its 7-foot cable – as when installing the Micro Link IR Receiver in a cabinet where the controlled equipment is behind closed doors. Small size: mounts in 1/2in diameter hole. 2 in deep. Quick-Connect 3.5mm Stereo Mini Plug on 7ft. cable for direct plug-in to Xantech Connecting Blocks. · Works in normal 3-wire mode (12VDC, IR, GND).
  • Infrared modulation frequency bandwidth: 30 – 60 kHz
  • IR reception range: Up to 80 feet, depending on remote control output strength and ambient conditions
  • Reception angle: 55 degrees off axis for 50% range reduction
  • Cable requirements: 3-conductor. Use 24 gauge up to 200ft, 22 gauge up to 600ft, 20 gauge up to 2000ft, 18 gauge up to 5000ft – unshielded OK
  • Max. transmission length: 1 mile using 18 gauge wire
  • Maximum current output: 100mA
  • Drives IR emitters through Xantech Connecting Blocks, Controllers, etc.
  • Dimensions: 1/2in diameter x 2in deep
  • Power requirements: +12VDC, 20mA
